MASS FIDELITY core - Core Speaker Ports and Indicators

www.massfidelity.com
4
1. SUB OUTBVEJPPVUQVUGPSXJSFETVCXPPGFS
2. AUX: Audio input for L/R analog signal
3. CONTROL: input for IR receiver eye
4. OPTICAL: input for optical digital signal
5. USB port: power out to charge USB devices
6. DC input jack: input for power supply
7. POWER keyTXJUDIVOJUPOPGGPSUPTUBOECZNPEF
8. POWER indicator: shows power and charging status (see p. 8)
PRODUCT REFERENCE: CORE
