Specifications
Components
Name & Specifications
Rated voltage
100~150Ω
Calf rest actuator
DDG24V-242/78-H
DC24V
100~150Ω
Backrest actuator
DDG24V-428/235-H
DC24V
Red- black:Output AC220V
White-black:Output AC110V
Black-black:Output AC12V
Blue-blue:Output AC28V
Transformer
A38-220V-24V/10A-19V/4A
AC110V AC220V
40~50Ω
Solenoid Valve
A382
Remark 1
AC→ alternating current DC→direct current V→volt Ω→ohm(above refers to the coil resistance)
Main components & Technical Specifications(Form 2)
