Controls and Instruments
410/420/430 - 001 8903 U1
UZEL
31
Grammer Seat
WARNING: DO NOT adjust the seat
when the tractor is in motion.
To adjust the seat proceed as follows:
Weight adjustment:
For maximum comfort it is important that you set the
suspension to suit your individual weight. Check the
weight shown in the weight indicator (1, Fig. 37-38),
it is calibrated in kilograms and pounds, It should be
set to your body weight. If adjustment is required,
climb up the tractor and seat, then unclip the handle
(2) and rotate it clockwise to increase the weight,
counter-clockwise to reduce the weight.
Test the seat suspension by alternately applying and
releasing your full weight on the seat. If you require
a softer or harder suspension, adjust the control
accordingly.
Forward and backward adjustment:
To adjust forward and backward movement of the
seat, pull the lever (3) up to disengage the runner
lock, then slide the seat either forward or backward
as required. Release the lever so it locks into position.
Fig. 37
Fig. 38
2
1
3
