Maintenance and Adjustment
66
410/420/430 - 001 8903 U1
UZEL
Fuel filler
WARNING: Do not fill with fuel when
the engine is hot or running.
To remove the fuel filler cap (rear of the two caps
above the hood) - press the cap downwards and turn
counterclockwise (Fig. 83). For further advice on
diesel fuel and filling the tank (see page 94-95).
Hood and side panels
Access to the top of the engine, fuel tank and radiator
is gained by removal of the hood and side panels
(Fig. 84) as follows:
1. Remove the top-side panels (1).
2. Remove the rear hood securing bolts located
behind the side panels (2).
3. Remove the front hood securing bolts located
behind the side panels (3).
4. Lift off the hood.
Fig. 83
Fig. 84
3
2
1
