Massimo MSU 1100 - CVT System

57
MAINTENANCE
CVT System(1100cc)
CVT---main technical parameter and specification
NO. main technical parameters
1.
CVT type Rubber PulleyCVT
2. Sheave angle of driving plate(°) 26
3.
Sheave angle of driven plate(°) 28
4.
Grooved surface angle ° 28
5.
Adjustment scope on speed
3.28～0.84
6. Dimension(a×b×h) mm 473×245×221
7.
Net weight kg
约 11
Tightening torque
No code Name Spe.
Torque
（N·m）
Assembly position
Thread
fastening agent
1 GB/T5789-1986
Plate bolt 10.9
level
M6x16 11±1 Torque cam
2 GB/T 5783-2000 Plate bolt 10.9 level M6x45 11±1 Driving wheel cover
3 21102-T02-0000 Locking nut M32x1.5 40±1
Combination of fixed
disk driving wheel
○
4 GB/T6184-2000 Locking nut M5 6±1 Swing block shaft
5 21001-T02-0000
Driving chain
connection bolt
M12x1.25 120±10 Engine crankshaft
6 21004-T02-0000
Driven/driving chain
connection bolt
M12x1.25
(Left-spin)
80±10 Gearbox input shaft
