4-5 Control Functions
then you should consult your local
dealer for maintenance in time.
Oil Overheat Indicator
The light will turn on when the UTV is
overheating
NOTE:
If the engine is overheating, stop the UTV
immediately. Do not start the engine again
until the UTV has been inspected and
repaired by a service center.
Low Battery charge indicator
Indicates a low charge on the battery. If light
is illuminated, re-charge battery. If recharging
the battery does not fix the issue, have a
service center inspect the battery and UTV.
Speedometer Unit
1. Left turn indicator light
2. “TRIP/ODO” button
3. Clock/Hour meter
4. Right turn indicator light
5. Tachometer
6. Odometer/Trip meter A / Trip meter B/Clock/Hour button
7. Metric/mile button
8. Speedometer
