14. Q-CONTROL (Available on D8000 & D16000 only)
This knob adjusts the curve of the bassboost.Turning this knob clockwise will make the
boosted frequency narrow and sharp. Turning this knob counter clockwise will extend
the boosted frequency range. By combining the bassboost frequency and the bassboost
level you can achieve a perfect bass response that matches your system.
15. CLIP LIMIT SWITCH (Available on D8000 & D16000 only)
This switch controls the amount of clip limit (on/off). When it is switched on the
amplifier will control the output level at the clipping point and reduce the distortion.
This will keep your amplifier at a low distortion level at the clipped signal.
18. POWER - LED
17. PROTECTION - LED
16. LIMIT INDICATOR
6
This LED will light up when the output is clipped or the amplifier over heats.
When the limit indicator lights up, the amplifier will hold or reduce the output
power to protect the subwoofer and amplifier. Reduce the gain or cool down the
amplifier when this indicator lights up continuously.
For: D 1200 / D 2400 / D 3600
