Mastech HY1803D - Protection and Indication Accuracy; Operating Environment; Operation Guide; Front Panel Controls Overview

- -
3
display 2.5%
1.7 Current indication accuracy: LED/LCD ± 2%+2digits, analogue
display 2.5%
1.8 Environment: 0 ~
+40
0
C relative humidity:<90%
2. OPERATION
2.1 Front panel controls.
(1) Current indication.
(2) Voltage indication
(3) Coarse adjustment of current.
(4) Coarse adjustment of output voltage.
(5) Negative output terminal.
