Mastech HY1803D User Manual

- -
5
current.
2.2.3 For restricted current protection mode switch on the power ON/OFF
switch 7, adjust controls 3 anti-clockwise to the minimum position, adjust
controls 4 clockwise to set the desired output voltage level and then connect
the load to the output terminals 5 & 6 Adjust controls 3 clockwise to set the
output current at the desired level for restricted current protection.
! 3. ATTENTION:
3.1 In the event of a short circuit at the output the current will limit at the
value set by the current controls, however the unit should be turned off and
the short circuit removed before continuing use.
3.2 The mains power must be switched off before servicing and servicing
should be referred to a qualified person.
