Mastech MS8239D User Manual

09 10
- Input Impedance: 10M
- Overload Protection:
200mV range: 250V DC or AC rms,
2V-600V ranges: 600V DC or AC rms.
- Frequency Range: 40 to 400Hz
- Response: Average, calibrated in rms of sine wave.
- Max. Input Voltage: 600V rms AC
Ω
3.2.3 DC Current
- Overload Protection: unfused.
- Max. Input Current:: 10A
- Frequency Range: 40 to 400Hz
- Response: Average, calibrated in rms of sine wave.
- voltage drop：2A range: 20mV, 10A range: 200mV
3.2.6 Continuity
2.000A
10.00A
0.001A
0.01A
- Overload Protection: unfused.
- Max. Input Current: 10A
- voltage drop: 2A range: 20mV,
10A range: 200mV
3.2.5 Resistance
200Ω
2kΩ
20kΩ
200kΩ
2MΩ
0.1Ω
0.001kΩ
0.01kΩ
0.1kΩ
0.001MΩ
20MΩ 0.01MΩ
- Open Circuit Voltage: 0.25V
- Overload Protection: 250V DC or 250V rms AC
Range
Function
Built-in buzzer will sound, if resistance
is lower than 50Ω±20Ω
Range
Resolution
±(2.0% of rdg+10 digits)
Accuracy
3.2.4 AC Current
2.000A
10.00A
0.001A
0.01A
±(3.0% of rdg+10 digits)
Range
Resolution
±(1.0% of rdg +3 digits)
Accuracy
±(1.0% of rdg +1 digit)
±(1.0% of rdg +5 digits)
- Open circuit voltage: approx. 0.5V
- Overload Protection: 250V DC or 250V rms AC
3.2.7 Engine Dwell
Range
Resolution
Accuracy
4CYL
0.1°
Range
Resolution
±(3°)
Accuracy
- Overload Protection: 250V DC or rms AC
0.1°
0.1°
6CYL
8CYL
