Mastech MS8301D User Manual

Input impedance: 10MΩ
Maximum input voltage: 600V DC or AC (RMS)
Measuring range: 1V~600V DC
Max input voltage: up to 600V for no more than 60 seconds.
DC Voltage
Measuring range
Resolution
Accuracy
±(0.5% of reading+3 digits)
6V
60V
600V
0.01V
0.1V
1V
AC Voltage
Measuring range
Resolution
Accuracy
±(0.8% of reading+5 digits)
6V
60V
600V
0.01V
0.1V
1V
Input impedance: 10MΩ
Maximum input voltage: 600V DC or AC (RMS)
Measuring range: 1V~600V AC
Max input voltage: up to 600V for no more than 60 seconds.
Frequency response:45Hz~65Hz
Resistance
Measuring range
Resolution
Accuracy
2KΩ
20KΩ
200KΩ
2MΩ
10MΩ
0.001KΩ
0.01KΩ
0.01KΩ
0.001MΩ
0.01MΩ
±(0.8% of reading+3 digits)
±(1.0% of reading+5 digits)
Overload protection:600V DC or AC (RMS)
Measuring range: 0Ω~10MΩ
Continuity Measurement
Function
Measuring
range
Resolution
Accuracy
When built-in buzzer
sounds, the resistance to
be tested is less than 40Ω
Open circuit voltage:
about 0.4V
Frequency
Through grade HZ/DUTY:
Measuring range
Resolution
Accuracy
60Hz
600Hz
3kHz
0.1Hz
1Hz
10Hz
±(1.0% of reading+5 digits)
- Overload protection:600V AC RMS
- The input voltage range:≥2V (input voltage will increase
when the frequency to be measured increases).
- Open circuit voltage: approx. 0.4V
- Overload protection: 600V DC or AC (RMS)
- Measuring range: 0Ω~10MΩ
1312
Accuracy: ±(% of reading + digits) with one year of
warranty.
Reference conditions: environmental
temperature is from 18°C~28°C, relative humidity
is not more than 80%.
Accuracy Indicators
Input polarity indication: automatically display "-"
symbol.
Power supply: AAA 1.5Vx2 batteries.
Dimension(LxWxH): 150x74x48mm
Weight: about 230g.
