* Remove test leads from the Meter before opening the Meter
case or battery cover.
* When servicing the Meter, use only specified replacement
parts.
* Before opening up the instrument, always disconnect from
all sources of electric current and make sure you are not
charged with static electricity, which may destroy internal
components.
* Any adjustment, maintenance or repair work carried out on
the meter while it is live should be carried out only by
appropriately qualified personnel, after having taken into
account the instructions in this present manual.
* A "qualified person" is someone who is familiar with the
installation, construction and operation of the equipment
and the hazards involved. He is trained and authorized to
energize and de-energize circuits and equipment in
accordance with established practices.
* When the instrument is opened up, remember that some
internal capacitors can retain a dangerous potential even
after the instrument is switched off.
* If any faults or abnormalities are observed, take the
instrument out of service and ensure that it cannot be used
until it has been checked out.
* If the meter is not going to be used for a long time, take out
the battery and do not store the meter in high temperature or
high humidity environment.
5
2.
2.
2.
2. DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
2.1
2.1
2.1
2.1 Instrument
Instrument
Instrument
Instrument Familiarization
Familiarization
Familiarization
Familiarization
① Range Control Button
② Data Hold Button
③ AC/DC Current or / Selecting Button
④ Socket for Transistor
Test
⑤ Function Switch/Power Switch
⑥ V/ Ω /F/Cx Input Jack
⑦ COM Input Jack
⑧ mA/ Input Jack
⑨ 10A Input Jack
