Master Audio
DSP206-608. Version 1.2 Apr 14 16
5.2.9 Channel Link
Output channels can be linked in order to set the same parameters on both. The
factory setting is that output channels 1&2, 3&4, 5&6 (and 7&8 in DSP608) are linked.
Turn the rotary knob set the link off.
5.3 System Menu
The System Menu allows the user to control and change parameters that are related
to the system behaviour and general operation. It can be accessed by pressing the
Menu key on the front panel. The available options are:
5.3.1 Load - Program Recall
The DSP unit has a built-in non-volatile memory that can store different program
setups. A program can be recalled using this menu. Use the rotary knob to browse
the desired program to load and click it to accept
Confirm your selection by turning the rotary knob until “YES” is in capital letters and
press enter again.
5.3.2 Save - Program Store
A program can be stored using this menu. The old program with the same program
number will be replaced. Once the program is stored in the flash memory, it can be
recalled at a later time, even after power down.
Select the number of slot where the current setting will be stored by rotating the
thumbwheel and pressing it to confirm.
After that, it is required to enter a name for the new preset, using the rotary wheel to
select the characters and the center click to confirm:
Once you finish typing the name of the preset, press again the Menu key to confirm.
Press the rotary knob to select “YES”. A confirmation message is displayed.
