General Information
Please read this manual prior to installing your Master-Bilt equipment. This information is based on good
refrigeration practice and should be used as a guide for installation and operations.
Delivery Inspection
Be sure to check for damage when this equipment is delivered by the carrier. Indicate damage on the
carrier’s Bill of Lading so that a claim may be filed.
Condensing Unit Specifications
Table 1. Specifications for system where evaporators use condensing unit power
Model
Sales
Nomanclature Location Compressor Refrig. Voltage HP
System
MCA
System
MOP
Wt.
LBS
R62R11D3CS(*) MAC-7
Cooler ZS11KAE-TF5 R449A 208-230/3
1
1/2
43.3 50
717
Freezer ZF13K4E-TF5 R449A 208-230/3 4
R62R11D4CS(*) MAC-8
Cooler ZS11KAE-TF5 R449A 208-230/3
1
1/2
53.4 70
717
Freezer ZF15K4E-TF5 R449A 208-230/3 5
R62R11D5CS(*) MAC-8C
Cooler ZS11KAE-TF5 R449A 208-230/3
1
1/2
56.0 70
717
Freezer ZF18K4E-TF5 R449A 208-230/3 6
(*) NOTE: For coated condenser coil, this place is “C”
Important Notice: Do not use reverse cycle defrost when the ambient is lower than -20
o
F.
Table 1.1 Specifications for system where evaporators use separate power source
Model
Sales
Nomanclature Location Compressor Refrig. Voltage HP
System
MCA
System
MOP
Wt.
LBS
R62R11D3CS(*) MAC-7
Cooler ZS11KAE-TF5 R449A 208-230/3
1
1/2
36.0 50
717
Freezer ZF13K4E-TF5 R449A 208-230/3 4
R62R11D4CS(*) MAC-8
Cooler ZS11KAE-TF5 R449A 208-230/3
1
1/2
44.0 60
717
Freezer ZF15K4E-TF5 R449A 208-230/3 5
R62R11D5CS(*) MAC-8C
Cooler ZS11KAE-TF5 R449A 208-230/3
1
1/2
44.5 60
717
Freezer ZF18K4E-TF5 R449A 208-230/3 6
