Master Bilt SPT-28 - Installation of Handle; Installation of Castors

3
Master bilt
1. Raise the COVER TOP as shown below.
2. Attach the HANDLE to the COVER TOP with screws included.
3. There are Handle and Screws in the attached Castor Box.
3. INSTALLATION OF HANDLE
1) Screw the castor (in rear side) and the castor brakes (in front side) by using
castor wrench.
2) Use the castor shims to level the cabinet, if necessary, by inserting them to
stems of the castors.
COVER CABINET *TOP
DOOR
ROTATION
CASTOR (WITH BRAKE)(2EA)
CASTOR(2EA)
CABINET
WASHER
BOLT
HANDLE
LID
4. INSTALLATION OF CASTOR AND CASTOR BRAKE
