BASIC OPERATION
CCR-23SF
CCR-49DF
CCR-72TF
WCR-23SF
1. Plug in and turn on the power switch located on the bottom of the top grille right side.
The Display panel will be lighted and make a beeping sound. The compressor will
begin to run.
2. The default temperature setting is No. “5”.
3. The compressor is automatically cycled by the electronic controller (PCB, F-Sensor).
4. The Defrost cycle is automatically controlled by the D-sensor, and the PCB.
5. Set toward “1” for higher temperatures and toward “9” for lower temperatures.
6. The interior light is activated by the door switch at the bottom of the top grille when
the door is opened.
7. Evaporator fan motor(s) will run after all doors are completely closed.
8. Good Air Flow in freezer unit is critical.
Be careful to load product so that it neither presses against the back wall, nor reaches
within four inches from the evaporator compartment.
FREEZERS
