BASIC OPERATION
WCC-23SR
WCR-23SR
1. The controller(thermostat) is located at the top inside of the unit.
2. The factory setting for the control is ‘Normal’, and maintains about 38˚F (3˚C) inside.
3. Set toward “Cool” for higher temperature and “Cold” for lower temperature.
4. The thermostat controls compressor’s cycling by sensing inside temperature.
5. Interior light is activated by the door switch when door is opened.
6. Cooling fans are activated by the door switch when door is completely closed.
REFRIGERATOR
OFF
COOL
COLD
NORMAL
Temperature Controller
(Thermostat)
