21
OPERATING INSTRUCTIONS
6. Connect the hose and regulator
assembly to the tank valve (See Fig. 5).
Hand tighten the quick coupling nut
clockwise to a full stop. DO NOT use a
wrench to tighten because it could
damage the quick coupling nut and
result in a hazardous condition.
7. Open the tank valve fully
counterclockwise. Use a soapy water
solution to check all connections for
leaks before attempting to light your grill.
See “Pre-operation Leak Testing" on
page 23. If a leak is found, turn the Tank
Valve off and do not use your grill until
the leak is repaired.
As shown in Fig. 6a gas tank must be place vertically. It is unsafe to operate the grill if the gas
tank is not vertical as shown in Fig. 6b.
WARNING: The Type I connective coupling (see Fig. 7) supplied with your grill must
not be replaced with a different type of grill/tank connection system. Removal will result
in loss of warranty, gas leakage, fire and severe bodily harm.
