Master Forge BG2294B-LB - Page 11

11
ASSEMBLY INSTRUCTIONS
7. Attach Door Hinges (O) and Hinge
Spacers (N) to Left & Right Side Panels
as
shown.
Note: DO NOT tighten the screws
of this
step now.
Hardware Used
M4x12 mm Screw x16
9. There are two adjusting screws on the
hinges which can be used to adjust the
doors as shown.
9
CC
O
N
7
CC
8. Attach Left Door (Z) and Right Door (Y) to
Door Hinges,
then tighten all of the screws,
including the screws in last step.
Hardware Used
M4x12 mm Screw x8
CC
Y
8
Z
CC
