Step 15: Place Cooking Grid and SFB
Cooking Grid
Place the cooking grids (F) onto the bottom
bowl (I) and SFB cooking grids (Y) onto the
SFB body (X).
Note: Always lift the cooking grids (F) with the
cooking grid handle (K) shown in Fig 15.
15
Step 16: Attach SFB Lid Handle and SFB
Lid
Attach the SFB lid handle (V) onto the SFB
lid (U) with four M4x10 screws (AA).
Attach the SFB lid (U) onto the SFB body top
(W) with two M6x20 bolts (CC
)
.
Hardware Used
16
ASSEMBLY INSTRUCTIONS
F
U
W
V
Y
M4x10
Screw
AA
x 4
M6x20
Bolt
CC
x 2
K
I
X
