Master Forge CBS24032L - Attaching Base and Dampers

ASSEMBLY INSTRUCTIONS
M5x12
Screw
BB
x 6
10
S
S
R
S
Step 9: Attach Legs
Attach legs (T) onto the bottom bowl (R) using six
M5x12 screws (BB) and six Ø6.5xØ18 washers (FF).
Hardware Used
Step 10: Attach Air Dampers
Attach air dampers (S) onto the bottom bowl (R)
using six M5x12 step screws (CC) and six M5 wing
nuts (EE).
Hardware Used
9
R
T TT
M5
Wing Nut
EE
x 6
M5x12
Step Screw
CC
x 6
Ø6.5xØ18
Washer
FF
x 6
10
