Master MFG Revolt - Securing the Sprayer Handle; Connecting the Wiring Harness

800.825.5397
7
PARTS
Secure Sprayer Handle to the Sprayer with Handle Adjustment
Knobs & Bolts. Tighten securely.
Use Phillips Screwdriver to tighten screw that is on the Wire Clamp
to secure wiring to frame.
TOOLS
3.
Secures Sprayer Handle to Sprayer
TOOLS
None
Locate the Wiring Harness Connectors at base of the Sprayer
Handle and exiting the back panel of the Sprayer.
Connect Wiring Harness Connectors. Ensure they are fully seated.
4.
Connects Battery Dock to Power Switch
PARTS
