MCA TIME CLOCK FILTER
TIME OF DAY DAYS TO NEXT REGEN
NORMAL DISPLAY
OR
CONFIGURATION
Program C1
1
st
Backwash
C2
Brine Draw
C3
2
nd
Backwash
C4
Rinse
C5
Brine Refill
P0 3 50 3 3 1-99
P1 8 50 8 4 1-99
P2 8 70 10 6 1-99
P3 12 70 12 8 1-99
P4 10 50 Skipped 8 1-99
P5 4 50 Skipped 4 1-99
P6 12 6 Skipped 12 1-99
P7 6 Skipped Skipped 4 Skipped
P8 10 Skipped Skipped 6 Skipped
P9 14 Skipped Skipped 8 Skipped
CLOCK AND
(3 SECONDS)
(3 SECONDS)
P8
OR
PROGRAM
CHART
CLOCK AND
Note: In the event that the filter is producing dirty water you may select P9 to help
Clean the filter.
