Filter Positioning:
1. Place Filter in desired position, far enough from walls and other
obstructions to allow for servicing the unit.
2. Place the Filter within reasonable access to a grounded 115V/60
HZ circuit and a legal drain line connection.
Filter Tank Loading:
1. Remove yellow caplug from top of tank. DO NOT CUT white
riser tube. Tube was prefitted at the factory.
2. The distributor is permantly attached to the vortech----centering is
not necessary. The top of the distributor will extend above the
top of the tank (this was prefitted at the factory).
3. Cover the top opening of the distributor pipe before filling the tank
with media.
4. Pour all filter media provided with the unit into the top of the tank.
See page one for your specific model number of unit to determine
the amount of media to load into the mineral tank.
5. Remove the material used to cover the top opening of the
distributor pipe.
Logix Control Valve:
1. When facing the front of the Logix timer, the inlet connection
(Figure 1) is located on the left and the outlet connection is on the
right. The control valve's inlet and outlet connections are either
3/4” copper or PVC equipped with gasket and nut.
Figure 1
Install the 256 bypass valve (See Figure 2) with inlet and outlet
handles facing upward. Place gasket into nut and secure 3/4” copper
