Installation and Operating Instructions for
268/762 Logix
Top Mount Combination Unit
Model #:
____ MP-NS-30T Acid Neutralizer and Softener
____ MP-NS-40T Acid Neutralizer and Softener
Shipping Carton Description / unit:
# of
cartons
Contents Description
1
Mineral tank
Distributor pipe installed
1
Brine tank
464 shutoff valve assembly. *NOTE:
268/762 Logix valved is shipped in
brine tank.
1
268/762
Logix control
valve
268/762 timer and backwash flow
control and bypass with 1” copper or
pvc connection
Calcite
½ CF Boxes
NS Mix
½ CF Boxes
System Description:
The combination unit has a Logix top mounted automatic control
valve with an impulse meter to initiate regeneration. The Logix
Valve is constructed of non-corrosive Noryl material and is rated at
a maximum working water pressure of 100 psi. It uses a 762
microprocessor based timer in conjunction with an internal impulse
meter to actuate regeneration in the following ways:
a. Microprocessor based water meter to initiate regeneration
b. Manual regeneration button to start an emergency
regeneration
c. Calendar day override
