3
PL
Nr
Część
Ilość
Nr
Część
Ilość
055 Śruba do ustawiania M10
1
063 Prawa boczna osłona 1
056 Podkładka Ф10xФ20x2.0
1
064 Śruba ST4.2x25 6
057 Końcówka drągu siodełka
2
065 Śruba plastikowaФ8x32 2
058 Blokada ustawiania drągu
1
066 Nakrętka M8 4
059 Siodełko
1
067 Śruba M6x15 4
060 Końcowa zaślepka
2
068 Nakrętka M6 4
061 Lewa boczna osłona
1
069 Śruba obciążenia silnika
(d=500MM)
1
062 Śruba ST4.2×20
8
070 AC Adapter długość=2000mm 1
POTRZEBNE NARZĘDZIA
Wielofunkcyjny klucz ze śrubokrętem
S10 S13 S14 S15
1 szt.
KLUCZ
IMBUSOWY S6
1
szt.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Master R22 and is the answer not in the manual?

Master R22 Specifications

General IconGeneral
Resistance TypeMagnetic
Drive SystemBelt
Display TypeLCD
Transport WheelsYes
Programs12
Dimensions (L x W x H)21.7 inches
Maximum User Weight150 kg (330 lbs)
