PARTS LIST
No.
Description
Qty
No.
Description
Qty
001 Main Frame 1 028 Bolt M8x35 2
002 Front Stabilizer 1 029 Transportation wheel 2
003 Rear Stabilizer 1 030 Nut M8 6
004 Idle Wheel Bracket 1 031 Sensor with Wire L=300mm 1
005 Seat Post 1 032 Screw ST2.9x12 2
006 Seat Sliding Tube 1 033 Hexagon Nut 7/8" 1
007 Handlebar Post 1 034 Washer Ø23xØ34.5x2.5 1
008 Handlebar 1 035 Bearing Nut II 7/8" 1
009 Handlebar Foam Grip 2 036 Boll Bearing 2
010 End Cap for Handlebar 2 037 Bearing Cup 2
011 Hand Pulse Sensor with Wire
L=750mm
2 038 Bearing Nut II 15/16" 1
012 Screw ST4.2x20 2 039 WasherФ24xФ40xδ3.0 1
013 Console 1 040 Belt Pulley with Crank 1
014 Computer Middle
Wire(L=850mm)
1 041 Belt 1
015 Bolt M5x10 4 042 Left Pedal YH-30X 1
016 Extension Sensor Wire
(L=950mm)
1 043 Right Pedal YH-30X 1
017 Power Supply Wire L=550mm 1 044 Nut M10x1.0 2
018 Hexagon Nut 1 045 Eyebolt M6x36 2
019 Motor 1 046 U Bracket 2
020 Bolt M8x15 4 047 Spring Washer Ø6 2
021 Washer Ф8xФ16x1.5 7 048 Nut M6 2
022 Curve Washer Ф8xФ16x1.5 1 049 Press Wheel 1
023 Washer Ф8xФ16x1.5 1 050 Bolt M8x20 9
024
The triangular tube plug I
2 051 Spring 1
025
The triangular tube plug II
2 052 Flywheel 1
026 Adjustable base M8x30 4 053 Seat Post Bushing 2
027 Big Flat Washer Φ8xΦ20x1.5 8 054 Round Knob 1
No.
Description
Qty
No.
Description
Qty
055 Adjustable Leveler M10
1
063 Right Chain Cover 1
056 Washer Ф10xФ20x2.0
1
064 Screw ST4.2x25 6
057 Seat Sliding Tube End Cap
2
065 Plasitc Bolt Ф8x32 2
058 Limit seat assembly
1
066 Nut M8 4
059 Seat Cushion
1
067 Bolt M6x15 4
