25www.mastercool.com
PROVA DELLE
EMISSIONI
CONFORMITÀ AMBIENTE ELETTROMAGNETICO - GUIDA (IN CONTESTO SANITARIO DOMESTICO)
Emissioni RF
CISPR 11
Gruppo 1
Questo apparecchio utilizza energia RF solo per il funzionamento interno. Pertanto, le
sue emissioni RF sono molto basse e non sono suscettibili di causare interferenze con
le apparecchiature elettroniche vicine.
Emissioni RF
CISPR 11
Classe B
Questo apparecchio è adatto per l’uso in tutti gli edifici, ivi compresi quelli domestici e
quelli direttamente collegati alla rete elettrica pubblica a bassa tensione che alimenta
immobili utilizzati a scopo abitativo.
DICHIARAZIONE DEL FABBRICANTE - IMMUNITÀ ELETTROMAGNETICA
Destinato all’uso (sanitario domestico) nell’ambiente elettromagnetico sotto specificato. L’acquirente o l’utente dovrebbe
assicurarsi che venga utilizzato in tale ambiente.
TEST DELL’IMMUNITÀ
LIVELLO DI PROVA IEC
60601
LIVELLO DI
CONFORMITÀ
GUIDA ALL’AMBIENTE ELETTROMAGNETICO
(CONTESTO SANITARIO DOMESTICO)
Scarica elettrostatica
(ESD) IEC 61000-4-2
Contatto: ± 8 kV
Aria ± 2 kV, ± 4 kV, ±
8 kV, ± 15 Kv
Contatto ± 8 kV
Aria ± 2 kV, ± 4 kV, ±
8 kV, ± 15 Kv
I pavimenti devono essere in legno, cemento
o piastrelle di ceramica. Se i pavimenti sono
rivestiti con materiale sintetico, l’umidità
relativa dovrebbe essere almeno del 30%
Campo magnetico
di frequenza
d’alimentazione (50,60
Hz) IEC 61000-4-8
30 A/m 50 Hz o 60 Hz 30 A/m 50 Hz e 60 Hz
I campi magnetici di frequenza
dell’alimentazione elettrica dovrebbero essere
ai livelli caratteristici di un tipico contesto
sanitario domestico.
DICHIARAZIONE DEL FABBRICANTE - IMMUNITÀ ELETTROMAGNETICA
Destinato all’uso in ambiente elettromagnetico (per l’uso sanitario di seguito specificata.
L’acquirente o l’utente dovrebbe assicurarsi che venga utilizzato in tale ambiente.
TEST
D’IMMUNITÀ
LIVELLO DI
PROVA IEC
60601
CONFORMITÀ
LIVELLO
AMBIENTE ELETTROMAGNETICO - GUIDA (IN CONTESTO
SANITARIO DOMESTICO)
RF irradiata IEC
61000 4-3
10 V/m
80 MHz – 2,7
GHz
80% AM a 1
kHz
10 V/m
80 MHz – 2,7
GHz
80% AM a 1
kHz
Distanza di separazione consigliata:
d = 1,2
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
d = 1,2
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
80 MHz a 800 MHz
d = 2,3
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
800 MHz a 2,7 GHz
dove P rappresenta la massima potenza in uscita del
trasmettitore in watt (W) secondo il fabbricante del trasmettitore,
mentre d è la distanza raccomandata in metri (m).
Intensità di campo da trasmettitori RF fissi, stabilita mediante
indagine elettromagnetica in loco,
a) dovrebbe essere inferiore al livello di conformità in ciascuna
gamma di frequenza.
b) Interferenze possono verificarsi in prossimità di
apparecchiature contrassegnate dal simbolo
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment d ue to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
NOTA 1 A 80 MHz e 800 MHz, vale la gamma di frequenza superiore.
NOTA 2 Le presenti linee-guida potrebbero non valere in tutte le situazioni. La propagazione elettromagnetica è
influenzata dall’assorbimento e dalla riflessione di strutture, oggetti e persone.
Le intensità di campo da trasmettitori fissi, quali stazioni-base per radiotelefoni (cellulari/cordless) e radiomobili
terrestri, radio amatoriali, trasmissioni radio AM e FM e trasmissioni TV non possono essere teoricamente previste
con precisione. Per valutare l’ambiente elettromagnetico a causa di trasmettitori RF fissi, è necessario prendere in
considerazione un’indagine del sito elettromagnetico. Se l’intensità di campo misurata nel luogo in cui viene utilizzato il
termometro supera il livello di conformità RF applicabile sopra indicato, è necessario verificarla per verificare il regolare
funzionamento dell’apparecchio. Se si notano prestazioni anomale, potrebbero essere necessarie altre misure, come il
riorientamento o riposizionamento dell’apparecchio.
DISTANZE CONSIGLIATE TRA TERMOMETRO E APPARECCHIATURE DI COMUNICAZIONE RF PORTATILI O MOBILI
Destinato all’uso (a scopo sanitario domestico) in un ambiente elettromagnetico in cui i disturbi RF irradiati siano
controllati. L’acquirente o l’utente può contribuire a prevenire le interferenze elettromagnetiche mantenendo una distanza
minima tra apparecchiature di comunicazione RF portatili e mobili (trasmettitori) e l’apparecchio come raccomandato di
seguito, in base alla massima potenza di uscita delle apparecchiature di comunicazione.
To Next Page
Loading...
