24 www.mastercool.com
NOTE IMPORTANTI
PULIZIA E CONSERVAZIONE:
Per garantire una lettura attendibile, assicurarsi che il sensore rimanga pulito..
La lente del sensore è la parte più delicata del termometro. Fare attenzione quando si pulisce la lente del sensore per
evitare di danneggiarla.
Per pulire la lente del sensore, utilizzare alcol o bastoncini cotonati inumiditi con alcol al 70~75%.
Lasciare asciugare completamente il sensore per almeno 1 minuto.
Mantenere l’apparecchio asciutto e al riparo da liquidi e luce solare diretta.
Temperatura di conservazione:conservare a una temperatura ambiente tra i -20 e i + 50°C (-4~122°F), UR<85%
Il sensore non deve essere immerso in liquidi.
Tenere il termometro troppo a lungo in mano può causare una lettura aumentata della temperatura ambiente e
portare a una lettura più bassa del solito della temperatura corporea.
SOSTITUZIONE DELLA BATTERIA :
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
Quando l’icona “batteria scarica” indica che la batteria è scarica, è necessario sostituirla immediatamente con *2
batterie AAA.
1. Aprire il coperchio della batteria e usando i pollici spingere fuori il coperchio della batteria (vedere figura 1).
2. Inserire le *2 nuove batterie AAA (come da figura 2)
3. Rimettere a posto il coperchio della batteria (vedere la figura 3)
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
RISOLUZIONE DEI PROBLEMI:
Messaggio
d’errore
Problema Soluzione
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
Errore 5~9, il sistema non funziona
correttamente.
Estrarre le batterie, attendere 1 minuto e
riaccendere. Se il messaggio riappare, contattare
l’assistenza-clienti.
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
Misurazione prima della stabilizzazione del
dispositivo.
Attendere che “Er1” scompaia.
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
La temperatura ambiente non rientra
nell’intervallo tra 10°C e 40°C (50°F ~ 104°F).
Lasciare il termometro per almeno 15 minuti a
riposo in una stanza con temperatura ambiente
tra i 10 e i 40°C (50°F~104°F).
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
(1) In modalità frontale: la temperatura rilevata è
superiore a 42,2°C (108°F)
(2) In modalità “Surface”: la temperatura rilevata
è superiore a 80°C (176°F)
Seleziona l’obiettivo all’interno delle specifiche.
Se il problema persiste, contattare il servizio di
assistenza.
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
(1) In modalità frontale, la temperatura rilevata è
inferiore a +34°C (93,2°F)
(2) In modalità “Surface”, la temperatura rilevata
è inferiore a -22°C (-7,6°F)
Ref No.032020
Press the ON/MEM button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode, you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement, wait icon stop flashing to be ready for next measurement.
Figure 2
Points for attention:
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is
-2.5 ~ -3.1°F (-1.4 ~ -1.7
°
C).
e. The “Limits of Agreement is 0.98.
f. The "Repeatability" is
0.36°F (0.20
°
C)
4. Measuring surface temperature:
4.1 After power on, press and hold the ON/MEM button, and press the START button one time for Infrared thermometer mode to see icon on your LCD
display. In this mode, you can get the target surface temperature.
4.2 When you press the START button, you will get the real time temperature immediately. If you press and hold the START button, the reading of measurement will
be continuously updated.
4.3 Applications include temperature measurements for water, milk, cloth, skin or other objects.
* Note: This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off:
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the ON/MEM button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range: It should be stored at room temperature between -4~122°F (-20~+50°C), RH
85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
Battery replacement
When the Low Battery” icon indicates the battery is low, the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting:
Error Message
Problem
Solution
Error 5~9, the system is not functioning properly.
Unload the battery, wait for 1 minute and repower it. If the message
reappears, contact the retailer for service.
Measurement before device stabilization.
Wait for “Er1 to disappear.
The ambient temperature is not within the range between 50
o
F~104
o
F (10
o
C~40
o
C).
Allow the thermometer to rest in a room for at least 15 minutes at room
temperature: 50
o
F~104
o
F (10
o
C~40
o
C).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2
o
C)
(2) In surface mode: Temperature taken is higher than 176°F (+80
o
C)
Please select the target within specifications. If a malfunction still exists,
please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34
o
C)
(2) In surface mode: Temperature taken is lower than 7.6°F (-22
o
C)
Device cannot be powered on to the ready stage.
Change with a new battery.
Warranty:
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover, it is shown on the inside of the device.)
Ex.SN:E512A000001, the firstE is External, the second number5” is the last number of manufacture year, the third and the fourth number12 is the manufacture
month, the others is the serial number.
Note: The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or unexpected
events at any time, please contact the dealers or nearest service address.
Warning: No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
Radiant Innovation Inc.
Http://www.radiantek.com.tw
Add: 1F, No.3, Industrial East 9
th
Road,
Science-Based Industrial Park, HsinChu, Taiwan 300.
Figure 1 Figure 2 Figure 3
Non si riesce ad accendere il dispositivo in
condizione “pronto” (Ready).
Cambiare la batteria con una nuova.
DICHIARAZIONE DEL FABBRICANTE - IMMUNITÀ ELETTROMAGNETICA
Destinato all’uso (a scopo sanitario domestico) nell’ambiente elettromagnetico sotto specificato. L’acquirente o utente
dovrebbe assicurarsi che venga utilizzato in tale ambiente.

Related product manuals
