30 www.mastercool.com
EMISSIETEST NALEVING ELEKTROMAGNETISCHE OMGEVING - BEGELEIDING (VOOR DE THUISZORGOMGEVING)
RF-emissies
CISPR 11
Groep 1
Deze unit gebruikt enkel RF-energie voor de interne werking ervan. Daarom zijn
de RF-emissies zeer laag en veroorzaken deze waarschijnlijk geen interferenties in
elektronische apparatuur in de onmiddellijke nabijheid.
RF-emissies
CISPR 11
Klasse B
Het apparaat is geschikt voor gebruik binnen alle instellingen, waaronder instellingen
met een woonfunctie en instellingen die rechtstreeks op een laagspanningsnetwerk
aangesloten zijn dat gebouwen met een woonfunctie van stroom voorziet.
FABRIKANTENVERKLARING - ELEKTROMAGNETISCHE IMMUNITEIT
Bedoeld voor gebruik in de elektromagnetische omgeving (voor thuiszorg) zoals hieronder gespecificeerd. De klant of de
gebruiker moet ervoor zorgen dat het in een dergelijke omgeving wordt gebruikt.
IMMUNITEITSTEST
IEC 60601 TEST
NIVEAU
NALEVINGSNIVEAU
ELEKTROMAGNETISCHE OMGEVING -
BEGELEIDING (VOOR DE THUISZORGOMGEVING)
Elektrostatische
ontlading (ESD) IEC
61000-4-2
Contact: ±8 kV
Lucht ±2 kV, ±4 kV, ±8
kV, ±15 kV
Contact ±8 kV
Lucht ±2 kV, ±4 kV, ±8
kV, ±15 Kv
De vloer moet uit hout, beton of keramische
tegels. Als vloeren bedekt zijn met synthetisch
materiaal, moet de relatieve vochtigheid
minstens 30% zijn
Stroom frequentie
(50,60 Hz) magnetisch
veld IEC 61000-4-8
30 A/m 50 Hz of 60 Hz 30 A/m 50 Hz en 60 Hz
Stroom frequentie magnetische velden
moeten op niveaus zijn die kenmerkend zijn
voor een typische locatie in een typische
thuiszorgomgeving.
FABRIKANTENVERKLARING - ELEKTROMAGNETISCHE IMMUNITEIT
Bedoeld voor gebruik in de elektromagnetische omgeving (voor thuiszorg) zoals hieronder gespecificeerd.
De klant of de gebruiker moet ervoor zorgen dat het in een dergelijke omgeving wordt gebruikt.
IMMUNITEIT
TEST
IEC 60601
TESTNIVEAU
NALEVING
NIVEAU
ELEKTROMAGNETISCHE OMGEVING - BEGELEIDING (VOOR DE
THUISZORGOMGEVING)
Uitgestraalde RF
IEC 61000¬4-3
10 V/m
80 MHz – 2,7
GHz
80% AM bij 1
kHz
10 V/m
80 MHz – 2,7
GHz
80% AM bij 1
kHz
Aanbevolen scheidingsafstand:
d = 1,2
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
d = 1,2
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
80 MHz tot 800 MHz
d = 2,3
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
800 MHz tot 2,7 GHz
Waarbij P het maximale nominale uitgangsvermogen is van
de zender in watt (W) volgens de zenderfabrikant, en d de
aanbevolen scheidingsafstand in meters (m). Veldsterktes van
vaste RF-zenders, zoals bepaald in een elektromagnetisch
locatieonderzoek,
a) moeten in elk frequentiebereik minder zijn dan het
nalevingsniveau.
b) er kan interferentie gebeuren in de buurt van apparatuur dat
wordt aangeduid met het volgende symbool:
Please read the instructions for use
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment d ue to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
OPMERKING1 Bij 80 MHz en 800 MHz geldt het hogere frequentiebereik.
OPMERKING2 Het is mogelijk dat deze richtlijnen niet gelden in alle situaties. De elektromagnetische propagatie wordt
beïnvloed door absorptie en weerkaatsing van structuren, voorwerpen en mensen.
Veldsterktes van vaste zenders, zoals basisstations voor radiotelefonen (mobiel/draadloos) en landmobiele radio’s,
amateurradio, AM en FM radio-uitzending en tv-uitzending, kunnen theoretisch niet nauwkeurig worden voorspeld. Om
de elektromagnetische omgeving door vaste RF-zenders te beoordelen, moet een elektromagnetisch locatieonderzoek
worden overwogen. Als de gemeten veldsterkte op de locatie waar de thermometer wordt gebruikt het geldende RF-
nalevingsniveau overschrijdt, moet er worden nagezien dat het apparaat normaal werkt. Als er abnormale prestaties
worden waargenomen, kunnen bijkomende maatregelen nodig zijn zoals het heroriënteren of herpositioneren van het
apparaat.
AANBEVOLEN SCHEIDINGSAFSTAND TUSSEN DRAAGBARE EN MOBIELE RF-COMMUNICATIEAPPARATUUR EN DE
THERMOMETER
Bedoeld voor gebruik in een elektromagnetische omgeving (voor thuiszorg) waarin uitgestraalde RF-storingen worden
gecontroleerd. De klant of de gebruiker kan helpen om de elektromagnetische interferentie te voorkomen door een
minimumafstand te behouden tussen draagbare en mobiele RF-communicatieapparatuur (zenders) en het apparaat zoals
hieronder wordt aanbevolen naargelang het maximum uitgangsvermogen van de communicatieapparatuur.
To Next Page
Loading...
