24 www.mastercool.com
69843-INST-R
If you have difficulty with a procedure please call
Mastercool’s Technical Service at 973-252-9119
WARNING: This product can expose you to chemicals including lead and Di (2-ethylhexyl) phthalate, which
are known to the State of California to cause cancer and birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
4. Open the couplers by turning them clockwise, press next
5. Open the Machine valves. Press next
6. The machine will now charge the programed amount of refrigerant. The refrigerant charge screen will
be displayed. This screen will display the amount of refrigerant in the internal tank, the refrigerant
being charged, the total amount of refrigerant programmed, the tank pressure, temperature and vehicle
pressure. When the charge is finished “process complete” will be displayed and the visual indicator will
turn green.
End of Charge / Hose Clearing Process:
This process allows for the verification of the operating AC pressures and the removal of refrigerant from the
hoses into the internal tank. The machine will then perform a short vacuum to prepare for the next vehicle.
Follow the instruction on the screen.
1. Close the high and low side valves on the machine, press next to continue.
2. Start the vehicle engine and turn AC system on high, press next to continue.
3. Verify the high and low side system pressures. Press next to continue.
4. Turn off the vehicle and allow the AC system pressures to equalize.
5. Close and remove the high side coupler. Press next to continue.
6. Start the vehicle, turn the AC system on high. Press next.
7. Open the valves on the machine. Press next.
8. Allow the AC system pressures to equalize. Press next
9. Close and remove the low side coupler, turn off the vehicle. Press next.
10. Hose clearing will be displayed. The tank graphic with weight will be displayed. The tank pressure and
temperature will be displayed.
11. The machine will recover any residual refrigerant and ready itself for the next vehicle.
12. Process Completed, will be displayed when finished.
