RESISTANCE MEASUREMENT FUNCTION
In Auto Check mode, press the "SELECT" key five times to select
resistance measurement function. The display will show resistance
measurement unit.
Connect the test leads across the object to be tested. Wait until the
reading is stable, then read the resistance reading on the display.
For measurements > 1 M, the meter may take a few seconds
to
stabilize reading. This is normal for high resistance measure-
ments.
When the test leads are open, "OL" will be displayed as an
overrange indication.
Before measurement, disconnect all power to the circuit to be
tested and discharge all capacitors thoroughly.
1.
2.
3.
NOTE:
model no. 052-0726-0 | contact us 1-800-689-9928
17
OPERATING INSTRUCTIONS
