FRONT PANEL
1.
2.
3.
Display
3 5/6-digit LCD, with a max.
reading of 5999.
"SELECT" Key
Used to select desired function
or mode as well as to turn on
or off the meter.
Test Probes
1
2
3
GENERAL SPECIFICATION:
3 5/6-digit LCD, with a max. reading of 5999.
Negative Polarity Indication: Negative sign " - " shown
on the display automatically
Overrange Indication: "OL" shown on the display
Sampling Rate: About 2 to 3 times/sec
Battery: 1.5 V button cell, LR44 or equivalent, 2 pieces
Low Battery Indication: " " shown on the display
Operation Environment: Temperature: 32 to 104ºF (0 to 40ºC)
Relative Humidity: < 75%
Storage Temperature: Temperature: 14 to 122ºF (-10 to 50ºC)
Relative Humidity: < 85%
Operating Altitude: 0 – 6560' (0 – 2000 m)
Size: 4 7/16 x 2 1/8 x 1/2" (112 x 54 x 12 mm) (for main body only)
Weight: About 2 1/2 oz (70 g) (including button cell)
Figure 1
6
