WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of
any other parts may create a safety hazard or cause damage to the tool.
Any attempt to repair or replace electrical parts on this tool may create a safety hazard
unless repairs are performed by a qualified technician. For more information, call the Toll-
free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
6515503023
Tapping screw ST5X30
4
2
6609040003
Spring Washer Φ5
4
3
5201780101
Front housing
1
4
4600740101
Washer
1
5
5101880101
Bushing
1
6
5403400101
Washer
1
7
6100710101
Spindle
1
8
6910550101
Ball
2
9
6100160101
Impact block
1
10
6910400101
Ball
24
11
5400580101
Washer
2
12
5500240101
Spring
1
13
6902061509
Pin
3
14
5101890101
Gear
3
15
6100720101
Shaft
1
16
5400250101
Washer
1
17
6801150121
Bearing
1
18
5403410101
Pendulum plate
1
19
5101900101
Inner gear ring
1
20
6511500812
Screw M5X8
2
PARTS LIST
!

MasterCraft 054-1222-8 Specifications

General

Brand	MasterCraft
Model	054-1222-8
Category	Cordless drill
Language	English
