PARTS LIST
WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of any other
parts may create a safety hazard or cause damage to the tool.
Any attempt to repair or replace electrical parts on this tool may create a safety hazard unless
repairs are performed by a qualified technician. For more information, call the Toll-free Helpline,
at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
!
Key #
Part #
Part Name
Quantity
1
4020030007
Chuck screw
1
2
1140050009
Chuck
1
3
4030010036
Tapping screw
3
4
2020210007
Compressing plate
1
5
2050070003
Positioning spring
1
6
3120080082
Torque setting ring
1
7
3150190130
Inner threaded ring
1
8
2040050113
Shaft
1
9
4010010092
Bearing
1
10
2050080148
Spring
1
11
2030020213
Washer
1
12
4080060001
Ball group
12
13
2010080094
Shaft sleeve
1
14
3150070068
Gear box
1
15
2030020101
Washer
1
16
4100020001
Snapring
1
17
2030020214
Washer
1
18
2010240034
Shaft lock ring
1
19
2010230012
Driving block
1
20
4110020003
Needle roller
6
