PARTS LIST
27
AIR-POWERED COIL ROOFING NAILER 058-8179-2
No. Description Qty. No. Description Qty.
1 Bolt 1 27 O-ring 50 X 1.8 1
2 Air deflector 1 28 Nail head 3
3 Slice 1 29 Nut 1
4 Pin 1 30 Sealing washer 1
5 Spring 1 31 Magnet 1
6 Bolt M6 X 25 8 32 Spring washer 4
7 Cylinder cover 1 33 Nail puller II 1
8 Bumper 1 34 Spring 1
9 Clap board 1 35 Bolt M4 X 10 1
10 O-ring 41.7 X 3 1 36 Protection cover 1
11 O-ring 18 X 2.65 2 37 Safety assembly 1
12 Compressed spring 1 38 Snap collar 1
13 Valve 1 39 Steel ball 1
14
O-ring 46.2 X 3.55
1 40 Spring 1
15 Sealing washer A 1 41 Adjusting pin 1
16 O-ring 38 X 4.5 1 42 Pin 2.5 X 1.8 1
17 Piston assembly 1 43 Safety plate 1
18 Cylinder 1 44 Trigger 1
19 O-ring 51 X 2.65 1 45 Pin 3 X 30 3
20 O-ring 50 X 3 1 46 Adjustable seat 1
21 Collar 1 47 Pin 2.5 X 22 1
22 O-ring 75 X 2.65 1 48 Spring 1
23 Gasket 1 49 Washer 1
24 Gun body 1 50 Pusher II 1
25 Protection 2 51 Adjusting screw 1
26 Bumper 1 52 Adjusting Nut 1
