IMPORTANT INFORMATION
11
FLUX-CORE WIRE FEED WELDER KIT 058-8194-4
Ground cable and clamp
The ground cable and the clamp are attached to the workpiece to form a closed circuit which allows
the flow of current needed to weld.
Welding Cable and MIG gun/torch
The welding wire is driven through the welding cable and the MIG gun/torch to the workpiece. It is
attached to the drive system and the gun trigger activates the drive motor.
Thermal Indicator
If the duty cycle of the welder kit exceeds the maximum level, the internal temperature of the welder
kit will exceed the allowable operating range, which in turn makes the thermal overload light glow
and the welder kit to be shut down automatically. Allow the welder kit to cool down for 20 minutes
until the thermal overload light turns OFF automatically. The temperature of the welder kit is then
within the allowable operating range.
Power cord
The power cord connects the welder to the 120 V power supply. Connect the 15 A plug into a
120 V/20 A receptacle to supply power to the welder.
