OPERATING INSTRUCTIONS
21
FLUX-CORE WIRE FEED WELDER KIT 058-8194-4
Types of welding beads:
Stringer bead Weave bead
• The stringer bead is formed by
travelling with the torch in a straight
line while keeping the wire and nozzle
centered over the weld joint
(fig L)
.
• The weave bead is made by weaving the
wire from side to side while moving with
the torch
(fig M)
.
fig L
MC-588194-13
fig M
MC-588194-14
