OPERATING INSTRUCTIONS
19
AIR-POWERED CLIPPED-HEAD FRAMING NAILER 058-8434-4
Mode conversion
To convert the nailer from one mode to the
other, remove the current trigger and install
the other trigger.
REMOVING THE CURRENT
TRIGGER
• Remove the O-ring (1) from the trigger
pin
(fig G) .
N
ote: A slot screwdriver may be used to
gently lift the O-ring from the end of the
trigger pin.
• Slowly remove the trigger pin (1), and
then the trigger. Use your thumb to
hold the trigger spring in place
(fig H) .
WARNING!
Potential hazard that could result in serious injury or loss of life.
• Hold the gun properly and mind the kick-back after each nail shot. Failure to
comply will lead to serious injury or loss of life.
fig G
MC-588434-10
1
MC-588434-11
fig H
1
