PARTS LIST
29
AIR-POWERED CLIPPED-HEAD FRAMING NAILER 058-8434-4
No. Description Qty. No. Description Qty.
1 Bolt 1 27 Bolt M8 X 25 4
2 Air deflector 1 28 Left orientation rubber 1
3 Deflector piece 1 29 Right orientation rubber 1
4 Pin 1 30 Sealing ring 1
5 Spring 1 31 Valve seat 1
6 Hex bolt M6 X 30 4 32 O-ring 16 X 1.6 1
7 Cylinder cover 1 33 Valve sleeve 1
8 Cylinder cover bumper 1 34 O-ring 6.1 X 1.8 1
9 Compressed spring 1 35 O-ring 6.4 X 2 1
10 O-ring 48.7 X 2.65 1 36 O-ring 9 X 1.8 1
11 O-ring 63 X 2.65 1 37 Switch spring 1
12 Head valve 1 38 Switch pipe 1
13 O-ring 50 X 3.55 1 39 O-ring 2.4 X 1.6 1
14 Main piston 1 40 O-ring 18 X 2.65 1
15 O-ring 67 X 2.65 1 41 Switch seat 1
16 Sealing ring 1 42 Adjuster seat 1
17 Cylinder 1 43 Compressed spring 1
18 Sealing ring 1 44 Gasket 1
19 O-ring 95 X 2.65 1 45 Pusher 1
20 Collar 1 46 Adjust screw 1
21 Bumper 1 47 Adjust nut 1
22 Sealing ring 1 48 Pin 3 X 30 2
23 Gun body 1 49 Pin 2.5 X 22 1
24 O-ring 62 X 1.8 1 50 Pin 2.5 X 18 1
25 Drive guide 1 51 Safety spacer II 1
26 Gasket 4 52 Trigger 1
