PARTS LIST
25
AIR-POWERED BRAD NAILER 058-8691-0
No. Description Qty. No. Description Qty.
1 Ball (Dw=2.5) 3 27 Pusher pipe 1
2 Compressed spring A 1 28 Adjustable stand 1
3 Bolt 1 29 Norm pin 1.5 x 8 2
4 Compressed spring 1 30 Compressed spring B 2
5 Air deflector 1 31 Adjustable nut 1
6 Bolt (M5x20) 4 32 Snap retainer 2 1
7 Spring washer 5 6 33 Adjustable stem 1
8 Cylinder cover 1 34 Safety stand 1
9 Sealing washer 1 35 Guide sleeve 1
10 O-ring 17 x 2.65 1 36 Bolt M3 x 8 1
11 Compressed spring 1 37 O-ring 7 x 1.5 2
12 O-ring 33.6 x 2 4 38 Trigger valve guide 1
13 Switch valve 1 39 Screw spring 1
14 Washer 1 40 O-ring 1.9 x 1.1 2
15 O-ring 24.2 x 3.1 1 41 Switch lever 1
16 Main piston 1 42 O-ring 11.2 x 1.6 1
17 Sealing washer 1 43 Trigger valve seat 1
18 Collar 1 44 O-ring 11.7 x 2.4 1
19 Cylinder 1 45 Compressed spring 1
20 Bumper 1 46 Fixed driver guide cover 1
21 Sealing washer 1 47 Bolt M5 x 25 2
22 Gun body 1 48 Pin sleeve 1
23 Guide stand 1 49 Pin 1
24 Pin 3 x 26 3 50 Bolt M4 x 16 2
25 Washer II 1 51 Quick release handle 1
26 Compressed spring 1 52 Movable driver guide cover 1
