PARTS LIST
26
AIR-POWERED BRAD NAILER 058-8691-0
If any parts are missing or damaged, or if you have any questions, please call 1-800-689-9928.
53 O-ring 1.9 x 1.2 1 68 Fixed lever jacket 1
54 Pin 1 69 Bolt M4 x 8 1
55 Driver guide 1 70 Fixed seat 1
56 Safety nozzle 1 71 Bolt M4 x 6 1
57 Inlay slice 1 72 Fixed magazine 1
58 Movable magazine 1 73 Pin 3 x17.5 1
59 Bolt M4 x 12 2 74 Safety spacer 1
60 Pusher A 1 75 Trigger II 1
61 Pusher pipe 2 76 Nut M4 1
62 Compressed spring 2 77 Bolt M4 x14 1
63 Bolt M4 x 10 2 78 Rubber handle case 1
64 Position seat 1 79 O-ring 36.3 x 3.55 1
65 Torsion spring 1 80 End cap 1
66 Pin 3 x18 1 81 Air inlet plug 1
67 Fixed lever 1 82 Air inlet plug cap 1
No. Description Qty. No. Description Qty.
