MasterCraft 062-3408-6 User Manual

headline bars
continuation tabs
notes
warnings
7
headline bars
continuation tabs
notes
warnings
TECHNICAL SPECIFICATIONS
DIMENSIONS
PERFORMANCE CHART
*Friction loss in piping not included in measurement.
11 3/8" (28.9 cm)
9 1/2" (24.2 cm)
3 5/8" (9.2 cm)
5 3/4 " (14.6 cm)
3/4 " NH
thread
7 1/2 " (19.1 cm)
Lift in feet/
metres
0’
(0 m)
5’
(1.5 m)
10’
(3 m)
15’
(4.6 m)
20’
(6 m)
25’
(7.6 m)
Submersible Utility
Pump Function
U.S. gallons/
litres per hour
1600
(6,056)
1500
(5,678)
1300
(4,921)
950
(3,596)
700
(2,649)
210
(794)
Non-submersible
Transfer Pump
Function
U.S. gallons/
litres per hour
950
(3,596)
840
(3,179)
730
(2,763)
600
(2,271)
400
(1,514)
170
(643)
