TECHNICAL SPECIFICATIONS
Lift 0’
(0 m)
5’
(1.5 m)
10’
(3 m)
15’
(4.6 m)
20’
(6 m)
25’
(7.6 m)
Flow 3300 U.S. GPH
(12.490 L/Hr)
2880 U.S. GPH
(10.902 L/Hr)
2520 U.S. GPH
(9538 L/Hr)
2040 U.S. GPH
(7721 L/Hr)
1500 U.S. GPH
(5678 L/Hr)
960 U.S. GPH
(3634 L/Hr)
*Friction loss in piping not included in measurement
DIMENSIONS
PERFORMANCE CHART
264 mm
10 3/8”
205 mm
8 1/16”
85 mm
3 1/3”
230 mm
9 1/16”
230 mm
9 1/16”
110 mm
4 1/3”
