INSTALLATION INSTRUCTIONS
5
7
6
Wrap thread tape around the threads
of a male PVC adaptor (not included).
Thread the adaptor into the front of
the pump (A).
8
Wrap thread tape around the threads
of a 1" (2.5 cm) adaptor, thread it
onto the tee.
Using PVC purple primer and PVC
cement, attach a 1 1/4" (3.2 cm) PVC
elbow (not included) onto the rigid PVC
pipe extending from the well seal.
Using PVC purple primer and PVC
cement, attach as many sections of
rigid PVC pipe and couplings (not
included) as needed to connect the
male PVC adaptor to the PVC elbow.
Ensure the pipe slopes slightly toward
the well (to prevent air from being
trapped in the pipe).
9
Spread the PVC cement on the outer
screw of the adaptor and inner screw
of the adjustable adaptor. Install the
1" (2.5 cm) adjustable adaptor into the
water system and seal with gasket.
10
