KEY PARTS DIAGRAM
PARTS LIST
No. Description Qty.
1 Diaphragm Switch 1
2 Pump 1
3 1 1/4” (3.2 cm)
NPT Ball Valve
1
No. Description Qty.
4 1 1/4” (3.2 cm)
NPT x 1 1/4” (3.2
cm) Slip Check
Valve
1
5 Sink Drain Screen 1
1
3
4
5
2
