11
ASSEMBLY INSTRUCTIONS
STEP 10 ATTACH THE DRAWERS BOTTOM-UP
Extend the bottom slides and attach the bottom drawer to the slides by sliding the slots at
the drawer's side panels onto the upright clips of the slides.
•
•
Secure the drawer to the slides by screwing four M4 x 5 cross-head bolts (11) through
the drawer to the slides.
Repeat the same procedure to attach the other two middle drawers to the slides, attaching
the lower one first.
•
NOTE: Read the procedure to attach the top drawer (the fourth point) carefully. Otherwise,
the product may be scratched.
11
NOTE: At this step, DO NOT use power tool. A magnetic cross-head screwdriver is preferred.
Otherwise, product damage may be caused.
1
2
3 4
