STEP 5 ATTACH THE BACK PANELS
STEP 4 ATTACH THE BACK TOP BEAM
8
model no. 068-1577-2 I contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
Attach the back panels (33) to the back of the cabinet with twenty-eight M6 x 16 hex socket head
screws (4). Insert the screws by hand. DO NOT tighten.
•
Attach the back top beam (37) to the side panels (3 & 32) with two M6 x 16 hex socket head
screws (4). Insert the screws by hand. DO NOT tighten.
The top edge of the top back panel should be inserted under the back top beam.
4
37
32
3
33
4
