WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of
any other parts may create a safety hazard or cause damage to the impact wrench.
Any attempt to repair or replace electrical parts on this impact wrench may create a safety
hazard unless repairs are performed by a qualified technician. For more information, call
the Toll-Free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
4030010114
ST3.9X25
4
2
4040030001
Spring washer 4mm
4
3
2020050059
aluminum casting
1
4
3140020017
"O" ring
1
5
2010080012
Shaft bushing
1
6
2030020034
Washer No.1
1
7
2040040088
Outer shaft
1
8
4080070001
Steel ball 5.5
2
9
2040200002
Torsion slot
1
10
4080040001
Steel ball 4
24
11
2030020035
Washer No.2
1
12
2050060178
Torsion spring
2
13
2040050022
Inner shaft
1
14
2010010027
Planetary gear
3
15
4110050003
Pin
3
16
2030020229
Washer No.3
1
17
4010010058
6002-2RS bearing
1
18
2010090067
Inner gear ring
1
19
3150070079
Gear box
1
20
4010010084
6000-2RS bearing
1
PARTS LIST
!
