MasterCraft 1323.2 User Manual

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
22
model no. 054-6821-2 | contact us 1-800-689-9928
No. Part No. Description No. Part No. Description
1 5610220000 Screw 33 5620061000 Screw
2 3130287000 Rear Cover 34 3421190000 Spindle Lock Cover
3 3121518000 Transparent Cap 35 5620069000 Screw
4 5610017000 Tapping Screw 36 2823121000 Collet Assembly
5 4891830000 Speed Adjustor 37 5620041000 Screw
6 5620017000 Hexagon Socket Screw 38 3320460000 Adjusting Knob
7 3120537000 Brush Cover 39 3123281000 Indicator
8 4960019000 Carbon Brush Assembly 40 3550854000 Shaft
9 2800005000 Brush Holder Assembly 41 5660005000 "E" Ring
10 5610106000 Tapping Screw 42 3660498000 Spring
11 3122798000 Cord Anchorage 43 3402540000 Lever
12 5610059000 Screw 44 5620466000 Screw
13 2823115000 Switch Assembly 45 5650407000 Wave Washer
14 3122851000 Seal Ring 46 5650013000 Washer
15 3125685000 Middle Housing 47 5620467000 Screw
16 3121064000 Cord Guard 48 3121637000 Chip Shield
17 4810002000 Power Cord Assembly 49 5620024000 Screw
18 3121049000 Rubber Spring 50 3322677000 Handle
1919 3700249000 Washer 51 2823122000 Lever Assembly
20 2822038000 Inner Wire Assembly 52 3703872000 Plate
21 2822039000 Inner Wire Assembly 53 5630015000 Nut
22 2740118000 Stator 54 2826784000 Mounting Assembly
23 5610050000 Tapping Screw 55 3123294000 Dust Bracket
24 3125687000 Fan Baffle 56 5620067000 Screw
25 2823131000 Rotor Assembly 57 3125119000 Base Plate
26 2823021000 LED Holder Assembly 58 5620074000 Screw
27 3421186000 Motor Housing 59 2822272000 Adjusting Assembly
28 5700056000 Ball Bearing 60 5650337000 Washer
29 5610076000 Tapping Screw 61 5650172000 Wave Washer
30 5630179000 Nut 62 5620032000 Screw
31 3551635000 Spindle Lock 63 3123435000 Adjusting Knob
32 3660174000 Stop Spring 64 5650014000 Washer
PARTS LIST

MasterCraft 1323.2 Specifications

General

Brand	MasterCraft
Model	1323.2
Category	Wood Router
Language	English
